The following video shows demonstrates how to connect the CCTV-02 surveillance microphone using a pre-made Siamese coaxial cable. Please take a look at our audio surveillance microphone installation guide to see additional examples of how to wire this microphone - with and without security cameras. These pre-made cables are a convenient installation method for professional and DIY installers HD security camera with a the MIC-CCTV-02 microphone.

#Cctv camera recorder pro install#

The above installation diagram shows how pre-made audio, video, power cables cables can be used to install an Security Camera with Audio Microphone Installation

cctv camera recorder pro

This diagram shows how to wire the microphone using the individual 12V DC power supply included with it. The MIC-CCTV-02 can be wired to a DVR using premade Siamese cable (power and coax) or a spool of RG59 Siamese cable. Alternatively, the camera and mic could use the individual DC power transformers that are included with them. Because the camera also uses 12V DC power, the CCTV camera and the audio surveillance mic can share the same power supply box. The red cable notes the power cable that is run from the microphone and camera to a 12V DC power supply box. In fact, the DVR does not even know if the mic is installed near the camera or not. The DVR allows the user to associate the audio from the microphone with any camera channel on the DVR. The orange coax cable connects the camera's video output to the video input of the DVR. The orange cable is the RG59 coaxial cable that is used to run the audio output of the mic to the audio input of the DVR. Please note that because the microphone uses its own power cable and coax cable, the mic does not actually need to be installed at the exact same location as the security camera that it will be paired with on the DVR. Although we are using an HD security camera in the diagram, this mic can be used with any type of security camera, including analog CCTV, AHD, HD-SDI, HD-TVI, HD-CVI, and network IP cameras because this is a stand-alone mic. The camera and the mic are both wired to an iDVR-PRO CCTV DVR for recording. The above wiring diagram shows how to install the MIC-CCTV-02 with an AHD-BL5H HD CCTV camera.

cctv camera recorder pro

See the below audio surveillance connection diagram for more information. Order the cable with this microphone and the converters are included.

#Cctv camera recorder pro Pc#

The Mic comes with its own 12V DC power supply and can be used with CCTV Camera Pros stand alone surveillance DVRs or PC based DVRs, such as Geovision.īecause the microphone has a female RCA input and most DVRs have RCA inputs for the microphone inputs, we include two BNC to RCA converters for each end of the plug and play cable.

cctv camera recorder pro

Installation of this microphone is very simple for a DIY installer to perform. Plug and play cables can be used with these microphones to easily run both the audio and power centrally back to the DVR. This microphone is stand alone as it does not rely on the power source from a security camera. The CCTV microphone is typically used as an add-on to CCTV cameras and other types of security cameras that do not have built-in audio. This audio surveillance microphone can be added to any surveillance system with audio input.
